Capsule Filters

Advantec - Disposable Capsule Filters
• CHOOSE - Capsules with PES membrane, PP depth media, or PTFE membrane
• Thermally fused polypropylene housings with broad chemical compatibility
• 78mm (3.07") in diameter • 57 psi (3.0 bar) maximum operating pressure
• 140°F (60°C) max. operating temp. • Vented ends for bleeding trapped air or drainage
• Capsule Filters are 100% integrity tested and are ISO certified

Advantec Capsule Filters are disposable self-contained filter units that are 100% integrity tested and ready to use. Filters encompass absolute membrane or depth-type filter media and are sealed in a chemically compatible all-polypropylene housing. Offered in five different filter media: PES, PTFE Hydrophobic, PTFE Hydrophilic (Not listed, inquire), Pleated Polypropylene, and Glass Fiber (Not listed, inquire) and retentive pore sizes range from 0.05 to 70 µm (Inquire for complete listing). Use for small batch point-of-use filtration or set in serial mode to further maximize throughput. Capsules are available in three different lengths and four end-connections. Typical applications include batch processing of a broad range of fluids including tissue culture media, fermentation broths, ground water, and point-of-use sterile filtration. Capsule filters are perfect for pilot/prototype studies with eventual scale-up as many of the same filter media are available in cartridge format with a larger effective filtration area.

Note, Advantec Capsule filters are not for use with air filtration.
